- Compare to Geneva GEN180, Designer H180GTG
- Square Profile Glass to Glass 180 Degree Hinge
- Designed For 3/8"-1/2" (10 mm to 12 mm) Tempered Glass
- Many Popular Finishes to Select From
- Self-Centering within 15 Degrees of Closing Position
- Commonly used in Residential Bath and Commercial Hotel Applications
- Reversible 5 Deg Pivot Pin For Jobs Requiring a Positive Closing Position
| MAXIMUM DOOR CAPACITY | 3/8" (10 mm) GLASS Approx. 5 lb/ft² | 1/2" (12 mm) GLASS Approx. 6.4 lb/ft² |
|---|---|---|
| DOOR WEIGHT | DOOR WIDTH | |
| Using 2 Hinges | 80 LBS (36 kg) | 28" (711 mm) |
| Using 3 Hinges | 120 LBS. (54 kg) | 32" (813 mm) |
NOTE: Do Not Exceed either maximum weight or width when choosing proper quantity of hinges.
| Product Name | FHC Glendale Series 180 Degree Glass to Glass Hinge - Brushed Nickel |
|---|---|
| Item No | GLEN180 |
| Compare To | GEN180|H180GTG |
| More Options | glen180 |
| Air Freight | Ships Air |
| Glass Fabrication | Use FHC Template SD1 For Glass Fab Template |
| Minimum Order | 1 Each |
| Product Height | 3-1/2" |
| Product Weight | 2 lb |
| Product Width | 2-3/16" |
| Ship Via | Ships UPS |
| Warnings | Not for use with laminated glass |
| Warranty | 3- Year Warranty |
